LED 3535
Ledestar high efficiency LED chip 3535 including 450nm LED, 660nm LED 730nm LED for horticulture lighting, boost photosynthesis, accelerate flowering, and shape plant morphology with high PPE. Compact, durable, and built for zero heat stress, it’s the ideal choice for commercial greenhouses, vertical farms, and high-value crop cultivation.
Key Features:
Industry Leading PPE Performance
Excellent Sulfur Resistance
Wavelength Options: 365nm/395nm/450nm/660nm/730nm
Replace 3737 LED
Lm-80 / UL Certification
View more SMD LED
Specifications
| Product image | Product Type | Code Number | Current(mA) | Typical Voltage(V) | Max Current(mA) | Color | CRI/Ra | Substrate | CCT(K)/WLP(nm) | PPE(μmol/J） | LPW(lm/W) | Download |
|
351S | LDR-3535CNAR660V0DR0V9 | 700 | 2 | 1000 | Deepred | / | Ceramics | 660 | 4.65 | / | / |
|
351V | LDR-3535CNAR660V0DR0L0 | 700 | 2 | 1000 | Deepred | / | Ceramics | 660 | 4.35 | / | / |
|
351H | LDR-3535CLAR660V0DR0H0 | 700 | 2 | 1000 | Deepred | / | Ceramics | 660 | 3.85 | / | / |
|
351B | LDR-3553CLZR660V0DR0P0 | 350 | 2 | 700 | Deepred | / | Ceramics | 660 | 4.4 | / | / |
|
351V Angel | LDR-3535CLAR660V0DR0L0 | 700 | 2 | 1500 | Deepred | / | Ceramics | 660 | 4.35 | / | / |
|
351V | LDR-3535CLFB450V0UB0K0 | 350 | 3 | 1000 | Blue | / | Ceramics | 450 | 3.4 | / | / |
|
351W | LDR-3535CNAB450V0UB0PA | 700 | 3 | 700 | Blue | / | Ceramics | 450 | 1.8 | / | / |
|
351V Angel | LDR-3535CLFB450V0UB0P0 | 350 | 3 | 1500 | Blue | / | Ceramics | 450 | 3.2 | / | / |
|
351V | LDR-3535CLZV400V0VA0H0 | 350 | 3 | 700 | UVA | / | Ceramics | / | / | / | / |
|
351S | LDR-3535CNAF730V0NR0H0 | 700 | 2 | 1000 | Infrared | / | Ceramics | 730 | / | / | / |
|
351V | LDR-3535CNF6570V065KHT | 350 | 3 | 1500 | White | 70 | Ceramics | 2700-6500 | 2.9 | / | / |
|
|
351V | LDR-3535CNF6580V060KHZ | 700 | 3 | 1500 | White | 80 | Ceramics | 2700-6500 | 2.5 | / | / |
|
|
351V | LDR-3535CNF6590V030KH0 | 700 | 3 | 1500 | White | 90 | Ceramics | 2700-6500 | 2.5 | / | / |
|
/ | / | / | / | / | / | / | / | / | / | / | / |
|
/ | / | / | / | / | / | / | / | / | / | / | / |
|
/ | / | / | / | / | / | / | / | / | / | / | / |
|
/ | / | / | / | / | / | / | / | / | / | / | / |
|
/ | / | / | / | / | / | / | / | / | / | / | / |
|
/ | / | / | / | / | / | / | / | / | / | / | / |
