Zhaga Module
From High-Efficiency Cob & Smd Leds To Customizable Led Modules, We Deliver Reliable, High-Performance Solutions For Global Lighting Manufacturers.
Key Features:
White LED Compare With LM301H, EVO series
Excellent Sulfur Resistance
CCT Options: 3000K-6500K
Lm-80 / UL Certification
View more SMD LED
Specifications
| Product image | Code Number | Current(mA) | Typical Voltage(V) | CRI/Ra | Flux(lm) | Power(W) | CCT(K)/WLP(nm) | LPW(lm/W) | Download |
|
LDR17312H112S1P36WL146W45 | 1050 | 36 | 70 | 7197 | 38 | 6000 | 190.8 |
|
|
LDR17312H112S1P-50WL146W45 | 700 | 72 | 70 | 9983 | 50 | 4200 | 201.2 |
|
|
LDR50504H42S8P50WL223W49R5 | 1100 | 47 | 70 | 9601 | 51 | 4200 | 205.5 |
|
|
LDR283516H48S8P50WL223W49R5 | 1100 | 47 | 70 | 11251 | 51 | 6200 | 216.7 |
|
|
LDR35354H416S1P50WL22W49R5 | 1050 | 48 | 70 | 9601 | 50 | 6000 | 192.4 |
|
